Flutter远程开发环境记录

2023-11-26 约 2179 字预计阅读 5 分钟

ArchLinux环境下的Flutter远程开发环境配置记录文，如有参考请注意时效性

Flutter

安装

安卓需要jdk8和jdk17，所以提前安装
pacman -Sy jdk8-openjdk jdk17-openjdk
flutter和android-sdk
pacman -S flutter android-sdk

ArchLinux可以从archlinuxcn源里安装flutter，开启源的方法我就不再赘述了，直接参考清华源的使用文档
android-sdk是Android开发必要的东西，如果只是远程flutter web则不需要

如果启用archlinuxcn之后安装程序报密钥错误,可运行以下两个命令处理

1
2
pacman-key --init
pacman-key --populate

配置

使用软件源安装的好处是可以跟随系统滚动更新，但是同样带来了一些使用细节上的问题需要处理

1、信任目录

1
2
3
4
git config --global --add safe.directory /opt/flutter

# 如何使用的用户不是root，从源里安装android-sdk时默认路径是`/opt/android-sdk`，后续安装工具链需要授予普通用户权限
chown -R $USER:$USER /opt/android-sdk

/opt/flutter是archlinux源安装flutter的默认路径，如果不是在这个路径则需要自己替换真实路径

2、通过`sdkmanager`安装安卓开发相关工具

切换jdk版本，因为 sdkmanager 最高只支持jdk8

1
2
3
4
5
6
# 以下命令都需要以su权限运行
# 查看当前jdk版本
archlinux-java status

# 设置默认jdk版本
archlinux-java set java-8-openjdk

添加sdk环境变量

1
2
export PATH=/opt/android-sdk/tools/bin:$PATH
export PATH=/opt/flutter/bin:$PATH

安装必要工具链

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
# Android开发需要三个东西，都可以用sdkmanager来安装

# 先列一下sdkmanager的基本使用命令
sdkmanager --list # 列出所有可安装或已安装的东西
sdkmanager --install "target_name;version" # 安装指定版本的sdk

# cmdline-tools
sdkmanager --install "cmdline-tools;latest"
# platform-tools
sdkmanager --install "platform-tools"
# platforms
sdkmanager --install "platforms;android-33"

检查
安装完成后，可以运行flutter doctor检查一下输出

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
[root@archlinux ~]# flutter doctor
Doctor summary (to see all details, run flutter doctor -v):
Could not parse java version from:

If there is a version please look for an existing bug https://github.com/flutter/flutter/issues/ and if one does not
exist file a new issue.
[✓] Flutter (Channel stable, 3.16.0, on Arch Linux 6.5.7-arch1-1, locale C.UTF-8)
[!] Android toolchain - develop for Android devices (Android SDK version 30.0.3)
    ✗ Could not determine java version
    ✗ Android license status unknown.
      Run `flutter doctor --android-licenses` to accept the SDK licenses.
      See https://flutter.dev/docs/get-started/install/linux#android-setup for more details.
[✗] Chrome - develop for the web (Cannot find Chrome executable at google-chrome)
    ! Cannot find Chrome. Try setting CHROME_EXECUTABLE to a Chrome executable.
[✗] Linux toolchain - develop for Linux desktop
    ✗ clang++ is required for Linux development.
      It is likely available from your distribution (e.g.: apt install clang), or can be downloaded from
      https://releases.llvm.org/
    ✗ CMake is required for Linux development.
      It is likely available from your distribution (e.g.: apt install cmake), or can be downloaded from
      https://cmake.org/download/
    ✗ ninja is required for Linux development.
      It is likely available from your distribution (e.g.: apt install ninja-build), or can be downloaded from
      https://github.com/ninja-build/ninja/releases
    ✗ pkg-config is required for Linux development.
      It is likely available from your distribution (e.g.: apt install pkg-config), or can be downloaded from
      https://www.freedesktop.org/wiki/Software/pkg-config/
[!] Android Studio (not installed)
[✓] Connected device (1 available)
[✓] Network resources

! Doctor found issues in 5 categories.

可以看到Android toolchain这一栏是一个感叹号，问题出在java版本不对和licenses，现在处理一下这两个问题

切换jdk17并执行licenses

1
2
archlinux-java set java-17-openjdk
flutter doctor --android-licenses

再次运行flutter doctor检查状态，可以看到前两项都打勾了

1
2
3
4
[root@archlinux ~]# flutter doctor
Doctor summary (to see all details, run flutter doctor -v):
[✓] Flutter (Channel stable, 3.16.0, on Arch Linux 6.5.7-arch1-1, locale C.UTF-8)
[✓] Android toolchain - develop for Android devices (Android SDK version 30.0.3)

ssh远程adb

安装好环境，还需要能连上设备，不同于常规的安卓开发，远程开发无法使用现成的虚拟机和真机，需要我们自己转发一下adb的连接

ssh隧道

重新声明，Flutter开发环境放在远程主机上，去远程的设备如笔记本，则是本机设备

使用过vscode远程开发的人都体验过vscode自带的端口转发和隧道功能，没有vscode的情况下，我们就需要自己用ssh操作了

最简单的方式就是ssh -L 本地主机端口号:localhost:远程主机端口号 user@ip

于是，转发adb的流量命令就是ssh -L 5037:localhost:5037 user@ip

在通过ssh建立隧道之前，需要先关掉本地设备上的adb服务，否则5037端口号被占用无法打通
关闭命令: adb kill-server

ssh config持久化

每次开发前都运行一下ssh -L就太麻烦了，可以直接在ssh的config文件里配置好

在~/.ssh/config文件中添加一下格式的内容

1
2
3
4
5
Host studio                             # Host 你自定义的名字
  HostName 192.168.123.123              # HostName 远程主机的IP地址或域名
  Port 22                               # Port 远程主机的ssh端口号，不写默认22
  User moexco                           # User ssh登录的用户名，不写默认root
  LocalForward 5037 localhost:5037      # adb端口隧道的配置

使用ssh studio来连接远程主机

远程adb连接真机

打开手机无线adb，连接跟本地设备同一个局域网络，这个操作略过

ssh转发5037端口之后，在远程或本地设备，正常使用adb连接设备即可

以下是我连接真机的例子

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
> $ adb pair 192.168.123.115:41021
Enter pairing code: 570121
Successfully paired to 192.168.123.115:41021 [guid=adb-99231FFAZ008ES-1ggJAb]

> $ adb connect 192.168.123.115:40827
connected to 192.168.123.115:40827

> $ adb devices
List of devices attached
192.168.123.115:40827   device

adb连上设备之后，正常运行flutter项目即可

1
flutter run -d 192.168.123.115:40827

使用neovim开发flutter

~~远程远程，开发工具也要远程~~

鉴于我是个懒人，所以选择在成品配置上二次修改，这里主要以LunarVim为例，它本身未支持flutter，所以需要让它能识别flutter并正常工作

安装

首先当然是安装neovim
pacman -Sy neovim
然后是安装LunarVim，这里直接使用官网提供的命令 LV_BRANCH='release-1.3/neovim-0.9' bash <(curl -s https://raw.githubusercontent.com/LunarVim/LunarVim/release-1.3/neovim-0.9/utils/installer/install.sh)

配置

基础配置每个人的习惯都不一样，这里主要记录flutter相关的部分

首先是选择插件flutter-tools.nvim
在~/.config/lvim/config.lua文件内加入以下内容:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
lvim.plugins = {
    {
        'akinsho/flutter-tools.nvim',
        lazy = false,
        dependencies = {
            'nvim-lua/plenary.nvim',
            'stevearc/dressing.nvim', -- optional for vim.ui.select
        },
        -- config = true,
        config = function()
            require("flutter-tools").setup {
                settings = {
                    enableSnippets = true,
                },
                widget_guides = {
                    enabled = true,
                },
                closing_tags = {
                    enabled = true,
                },
                lsp = {
                    on_attach = require("lvim.lsp").common_on_attach,
                    color = {
                        enabled = true,
                        background = false,
                        foreground = false,
                        virtual_text = true,
                        virtual_text_str = "■",
                    }
                }
            }
        end,
        ft = "dart",
    }
}

修复卡死bug，继续在配置中加入:

1
lvim.builtin.treesitter.ignore_install = {"dart"}
